features功能特性
|
|
The processor(处理器)
|
Cortex A9 Dual-core 1.2 GHZ The processor
Cortex A9 1.2GHZ 双核处理器
|
|
Memory capacity (内存容量)
|
ROM：4G RAM：1G
|
|
The operating system (操作系统)
|
Android 4.2
|
|
Wireless communications (无线通讯)
|
GPRS（Optional）
|
GPRS, EDGE , 4-band 900/1800，850/1900
|
|
WCDMA（3G， Optional）
|
band 850/2100，Cat.8 HSDPA Cat.6 HSUPA
|
|
WIFI（standard）
|
Conform to the IEEE 802.11b/g
|
|
Bluetooth（Optional）
|
Conform to the Bluetooth 4.0
|
|
Display
(显示屏)
|
4.3寸IPS display, The resolution of the 480*800, Gabo Lingual perspective, the sun is visible
4.3寸IPS屏, 分辨率480*800, 高清全视角，阳光下可见
|
|
Touch screen
(触摸屏)
|
Support more capacitive touch
支持多点电容触摸
|
|
Indicator light
(指示灯)
|
Network indicator light, charge indicator
网络指示灯，充电指示灯
|
|
audio
(音频)
|
Support the speech
支持语音播报
|
|
Micro SD card
( Micro SD卡)
|
Support 32 gb MICRO SD card
支持32G MICRO SD卡
|
|
Data security
(数据安全)
|
Product is the data security protection, in a completely off electricity (remove the battery and the power converter), data is not lost
产品具有防掉电数据安全保护，在完全掉电（卸下电池及不外接电源）的情况下，数据不丢失
|
|
GPS indicators
（Optional）
(GPS指标)
|
Channel: channel 12 通道：12通道
Receive types: L1, C/A code and carrier phase smoothing 接收类型：L1，C/A码，带载波相位平滑
Heavy capture: < 1 s 重捕获：< 1s
The latest ASIC chip; A squadron of patent algorithms; EVEREST multipath suppression technology
最新的ASIC芯片；COAST专EVEREST多路径抑制技术
Error range: < = 10 meters 误差范围： <=10米
|
|
Navigation map
(导航地图)
|
Support navione, baidu, Google, gold and other navigation map
支持凯立德、百度、谷歌、高德等导航地图
|
|
The input method
(输入法)
|
Full-screen handwriting, half screen handwriting, strokes and pinyin, Numbers, letters, symbols
全屏手写，半屏手写，笔划，拼音，数字，字母，符号
|
|
Physical interface
(物理接口)
|
High-speed USB2.0 interface equipment end, 3.5 stick related plug-in interface
高速USB2.0设备端接口，3.5棍插充电接口
|
|
camera
摄像头（Optional）
|
The rear 500 w megapixel camera with flash
后置500W像素摄像头， 带闪光灯
|
|
The flashlight
(手电筒)
|
Low power consumption LED lights lighting, emergency use
低功耗LED灯照明，应急使用
|
|
The fingerprint module指纹模块（Optional）
|
Sensor types: inductive, image size: 256 * 288, image resolution: 500 dpi
传感器类型：电感式，图像大小：256*288， 图像分辨率：500DPI
|
|
Registration time < 3 seconds, compare the time < < 0.1 s, than in time of 0.5 seconds (100)
注册时间 < 3秒，对比时间<0.1s，比对时间 < 0.5秒（100枚）
|
|
Boomed from < 0.1%, recognize false rate < 0.001%, fingerprint capacity: 512
拒真率<0.1%, 认假率<0.001%, 指纹容量：512枚
|
|
A dimensional barcode一维条码（SE955/N43XX）（Optional）
|
|
Read code system
(识读码制)
|
Can read all kinds of main one-dimensional bar code: Code 39、Code 93、Code 128、Codebar、EAN-13、EAN-8、UPC-A、UPC-E、ITF 14、UCC/EAN-128、ITF 25、Matrix 25、EAN-128、ISBN
可识读各种主要一维条码：Code 39、Code 93、Code 128、Codebar、EAN-13、EAN-8、UPC-A、UPC-E、ITF 14、UCC/EAN-128、ITF 25、Matrix 25、EAN-128、ISBN
|
|
Read distance
(识读距离)
|
0 cm～50 cm
|
|
Read rate
(识读率)
|
First read rate of 99% or more, the error rate of 0.01% or less, false reject rate is 0.01% or less
首读率≥99％，误码率≤0.01％，拒识率≤0.01％
|
|
Two dimensional barcode二维条码 （Optional）
|
|
Moto-SE4500
|
Hardware decoding, the decoding speed and error rate of 0.01% or less
硬件解码，解码速度快，误码率≤0.01％
|
|
Newland-EM4100
|
Hardware decoding, the decoding speed and error rate of 0.01% or less
硬件解码，解码速度快，误码率≤0.01％
|
|
RFID （Optional）
|
|
Ultra high frequency
超高频（915MHz）
|
More than 3 m distance for EPC C1 GEN2 / ISO18000-6 - c protocol of 900 MHZ tag read operation (associated with tags and antenna)
2-3m以上距离针对EPC C1 GEN2 /ISO18000-6C协议的900MHz的标签进行读操作(与标签和天线有关)
|
|
High frequency
高频（13.56MHz）
|
0 ~ 7 cm range for ISO15693, ISO14443 double deal 13.56 MHz tags for reading and writing (associated with tags and antenna)
0~7cm距离内针对ISO15693、ISO14443双协议13.56MHz的标签进行读写(与标签和天线有关)
|
|
Low frequency
低频
|
125 K / 134.2 K animal ear tag
125K/134.2K动物耳标
|
|
PSAM
|
Support two PSAM card
支持两张PSAM卡
|
|
High frequency (CPU card read)
高频（CPU卡读取）
|
Support the CPU card read and write, used with PSAM
支持CPU卡的读写，配合PSAM使用
|
|
Active in close communication有源近距离通讯 （Optional Customers need to provide module）
|
|
Active 2.45 G
(有源2.45G)
|
Distance is 200 m, 200 m label can be read all at once
距离200m，200张标签可以全部一次性读取
|
|
433M
|
Read more than 200 m distance, distance is adjustable
读取距离200m以上，距离可调
|
|
Battery performance电池性能
|
|
The battery
（电池）
|
4100 mah lithium polymer battery, standby time: more than 150 hours, working time: more than 8 hours, ac adapter charging (1 a)
4100mAh锂聚合物电池,待机时间：大于150小时,工作时间：大于8小时,交流适配器充电(1A)
|
|
The battery standby time
（电池待机时间）
|
After a full charge, the wireless communication function on standby, after 360 hours, can run normally
电池充满电后，关闭无线通讯功能待机，360小时后，能正常运行
|
|
Battery charging time
（电池充电时间）
|
Charging time < 4.5 hours
充电时间＜4.5小时
|
|
Charging time
（充电工作时间）
|
More than 8 hours (a charge)
8小时以上（一次充满电）
|
|
The work environment工作环境
|
|
Operating temperature
（操作温度）
|
-20℃~50℃
|
|
Storage temperature
（存储温度）
|
-20℃~70℃
|
|
Relative humidity
（相对湿度）
|
10%~90%RH，不凝结
|
|
Protection grade
（防护等级）
|
IP65
|
|
Physical parameters物理参数
|
|
The total weight
（总重量）
|
Less than 300 grams (including battery, charger are not included)
小于300克（包括电池，不包括充电器）
|
|
The fuselage size
（机身尺寸）
|
148 (length) x 77.5 (width) x 27 (thick) plus or minus 2 mm
148（长）×77.5（宽）×27（厚）± 2 mm
|
|
The attachment附件
|
|
Standard
（标准）
|
1 1 lithium battery, charger, USB data line 1.
锂电池1个，充电器１个， USB数据通信线１条。
|
